JUKI Exceed HZL-F400 Sewing Machine

Also Available in Our Retail Store
Call for More Information or Special Promotions

Machine Manual

The Juki HZL-F400 has included numerous features to ensure you get amazing stitch quality every time. No matter if you’re a beginner or a sewing pro, you’ll be able to complete your garments, home décor projects and quilting projects with professional results every time. The Juki HZL-F400 gives you the option to select frequently used stitches and patterns through the touch panel. You can access the other 175 Stitch Patterns and 3 Fonts choices through the LCD screen and navigation keys.

Main Features
Direct Stitch Pattern Selection
Frequently used stitch patterns can be selected directly through the Direct Select mode. Piecing, Applique, Blanket stitch for applique, Overlocking, Invisible Hemming, Stretch Stitch and more all at the touch of a button. Stitch settings, patterns and recommendations for the best presser foot can all be seen on the machine's LCD screen display. The keypad allows you to quickly and easily select lettering and to adjust settings. Stitch can be adjusted with just the turn of a dial!

Customization and Control
Combine decorative stitches and lettering into new sequences. You can save up to 70 patterns! You can program the needle up/down position, automatic thread trimming, and foot control trimming with just the push of a button. Also set the contrast of the LCD screen, change the volume of the machine buzzer, select from 8 different language settings, and use the on-board sewing guide when you need a little help.

Industrial Sewing Machine Technology
In order to provide beautiful seams and outstanding feed performance, JUKI adopted the box feed system. The conventional feed mechanism is oval motion. On the other hand, the box feed moves the feed dog in a box motion. This eliminates material shrinking and shifting. This accurate feeding system provides superior stitch quality for a variety of light to heavy weight fabrics.

Capable of Sewing a Width Range of Fabrics
Thick fabrics can be sewn with ease. Leather, denim, and canvas are no problem for this machine. No fabric shrinkage even while sewing on extra lightweight materials.

Industrial Quality Buttonholes
Using a unique sensor method, HZL-F series sews beautiful buttonholes regardless of the type of material and overlapped sections. 16 types of buttonholes are available for your needs. Now it is possible to adjust the cutting width of the buttonholes in 3 steps.

Foot Controller with Thread Trimming Function
HZL-F series trims both needle and bobbin threads automatically by pressing the heel side of the foot controller. It is also possible to trim threads with a button located at machine body. With this feature you can concentrate on your project while automatically cutting the thread!

Perfect Stitch and Needle Placement
The Exceed series now has a feature that allows you to move the position of a complete pattern without changing the width, as well as variable needle positions that allows you to place the needle anywhere you want.

Wide Sewing Space
HZL-F series has a wider underarmspace, with a wider table. It is more enjoyable and comfortable to work with large projects.

Knee-lifting Lever
Presser foot can be raised and lowered by the knee-lifting lever. You now can have both hands free when trying to line up those hard to handle fabrics. The presser foot lift is up to 12 mm when the lever is used

Accessories

• Zig zig foot
• Overcasting foot
• Blind hem foot
• Auto buttonhole foot
• Manual buttonhole foot
• Patchwork foot
• Quilting free motion foot
• Walking foot
• Zipper foot
• Quilt guide
• Auxiliary spool pin
• Hard shell cover
• Bobbins (4)
• Spool caps (small, medium, large)
• Special screwdriver
• Auxiliary spool pin
• Knee lifter lever
• Seam ripper
• Lint brush
• Needle pack
• Twin needle
• Foot control
• Power cord
• Instructional manual
